45 Axiom Pro User Guide
Parameter: MIDI Port
Value Range: O, A, A&O, B, B&O, A&B, All, Off
Each of the four zones can be individually configured to transmit MIDI data on any combination of
Axiom Pro ports:
• A Axiom Pro 61 11 USB A
• B Axiom Pro 61 11 USB B
• O Axiom Pro 61 11 MIDI Out (External MIDI port)
• All MIDI data is transmitted on all ports
• Off MIDI data is not transmitted
Parameter: Program
Value Range: 0-127
This parameter sends Program Change MIDI messages on your selected keyboard zone’s MIDI
output channel when an Axiom Pro patch is loaded Note that Program Change messages are only
sent on active zones Please see the “Edit Mode > Zones” section of this guide to learn how to
activate/deactivate zones
Parameter: BankLSB
Value Range: 0-127
This parameter sends Bank LSB messages on
your selected zone’s MIDI output channel when
an Axiom Pro patch is loaded Note that Bank
LSB messages are only sent on active zones and
will not have any effect until a Program Change
message is sent
Parameter: BankMSB
Value Range: 0-127
This parameter sends Bank MSB messages on your selected zone’s MIDI output channel when an
Axiom Pro patch is loaded Note that Bank MSB messages are only sent on active zones and will
not have any effect until a Program Change message is sent
11 The 25 and 49-note versions of Axiom Pro will appear as “Axiom Pro 25” and “Axiom Pro 49” respectively.
✓ NOTE: If you load an Axiom Pro
patch containing program change,
bank LSB, or bank MSB messages
for the zones, each zone will transmit
its assigned program change or
bank LSB/MSB message when
the patch is loaded. If you would
like to load a patch without sending
these messages, make sure that the
keyboard icon is unchecked on the
Load page. Please see the “Loading
Patches” section in the “Saving and
Loading your Axiom Pro Patches”
chapter to learn more about this topic.
