e Appendix C: Technical Info
Sample Frequency Selections
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Analog Input Connectors
Pod:
Two balanced XLR/TRS combination mic/line inputs
Base Station:
Two balanced XLR mic inputs
Four balanced 1/4" TRS line inputs
Two 1/4" TS high-impedance instrument inputs
Analog Output Connectors
Pod:
Two balanced 1/4" TRS line-level outputs
Base Station:
Eight balanced 1/4" TRS line-level outputs
Analog Insert Connectors
Base Station:
Two unbalanced 1/4" TRS line-level inputs/outputs
Digital Input/Output Connectors
Pod:
One 6-pin FireWire input/output
Base Station:
One 6-pin FireWire input/output
Power Requirements
Both units can be powered by the 6-pin FireWire connection or
by the DC Power Supply included.
In the U.S.: 120 VAC/60 Hz In
12V DC Out
Outside the U.S.: 100 VAC-240 VAC/50-60 Hz In
12V DC Out
Physical Dimensions and Weight
Pod
Height:
2.1 in/53 mm
Width: 8.0 in/203 mm
Depth: 4.1 in/104 mm (including front knobs and
rear jacks)
Weight: 1.8 lb/0.8 kg
Base Station
Height:
4.4 in/112 mm (4.6 in/117 mm with feet)
Width: 10.8 in/274 mm
Depth: 7.1 in/180 mm
Weight: 6.1 lb/2.8 kg
LOUD Technologies Inc. is always striving to improve our prod-
ucts by incorporating new and improved materials, components,
and manufacturing methods. Therefore, we reserve the right to
change these specifications at any time without notice.
“Mackie.”, “Onyx,” and the “Running Man” are registered
trademarks of LOUD Technologies Inc. All other brand names
mentioned are trademarks or registered trademarks of their
respective holders, and are hereby acknowledged.
©2006 LOUD Technologies Inc. All Rights Reserved.
Onyx Satellite Specifications
Frequency Response
Mic Input to Line Output (Gain @ unity):
@48 kHz
20 Hz to 20 kHz, ±1 dB
@96 kHz
20 Hz to 40 kHz, ±1 dB
Distortion (THD & IMD)
Mic Input to Line Output (@ +4 dBu output):
THD+N: < 0.02%, 20 Hz to 20 kHz BW,
1 kHz input @ +4 dBu, preamp at unity gain
Dynamic Range (A-weighted, typical)
103 dB (Mic In to Line Out)
Noise
Signal-to-Noise (A-weighted, typical):
>103 dB (ref. +0 dBu, Mic In to Line Out, Gain @ unity)
Equivalent Input Noise (E.I.N.), 20 Hz to 20 kHz Bandwidth,
150Ω source impedance, typical:
–110 dBu @ +60 dB gain
Common Mode Rejection Ratio (CMRR)
Mic In: >40 dB @ 1 kHz, Gain @ maximum, typical
Crosstalk
Mic Input to Line Output:
< –80 dB @ 1 kHz, +10 dBu signal on adjacent input,
150Ω source impedance
Input Gain Control Range
Mic In: 0 dB to +60 dB, ±1 dB
Line In: –20 dB to + 40 dB, ±1 dB
Phantom Power
+48 VDC (±20%)
Rated Output
Line: +4 dBu nominal
Maximum Rated Output:
+18 dBu @ Balanced Line-Level Outputs
Input Impedance
Mic Input: 2.4 kΩ balanced
Inst Input: 1 MΩ
Line: 20 kΩ balanced, 10 kΩ unbalanced
Output Impedance
Line: 100 Ω balanced
Signal Level LEDs
–40 dB, –20 dB, –10 dB (normal operating level),
OL = 0 dB FS
