Onyx Satellite: Post-Production and Surround Mixing
This illustrates a 5.1 surround sound setup using two video decks con-
nected to Line 1 and 2 on Inputs 1 and 2. A microphone is connected to
the mic input on Input 1 for voiceover.
2 INPUT
(TIP=SEND
RING=RETURN)
1 LINE LINE
INSERT
ON YX MIC PRE
4 3 2 1
6 5
B
OUTPUTS
(BAL/UNBAL)
LINE LINE
INSERT
ON YX MIC PRE
CR OUT
A
2/R 1/L
2/R 1/L
1 INPUT
(TIP=SEND
RING=RETURN)
2
Condenser
Microphone
Left and Right
Front
Left and Right
Rear
Center
Digital Audio Workstation
Subwoofer
Video Deck 1 Video Deck 2
