background image

68 _Maintenance

MAINTENANCE PARTS

To avoid print quality and paper feed problems resulting from worn parts,

and to maintain your machine in top working condition the following

condition, the following items will need to be replaced after the specified

number of pages, or when the life span of each item has expired.

We highly recommend that this maintenance be performed by an authorized

service provider, dealer or the retailer where you bought the machine. The

warranty does not cover the replacement of the maintenance parts after

their lifespan.

Checking replaceables

If you experience frequent paper jams or printing problems, check the

number of pages the machine has printed or scanned. Replace the

corresponding parts, if necessary.
1. Press Menu until System Setup appears on the bottom line of the

display and press OK.

2. Press the left/right arrow until Maintenance appears and press OK.
3. Press the left/right arrow until Supplies Life appears and press OK.
4. Press the left/right arrow until the item you want appears and press OK.

Supplies Info: Prints the supply information page.

Total: Displays the total number of pages printed.

ADF Scan: Displays the number of pages scanned using the ADF.

Platen Scan: Displays the number of pages scanned using the

scanner glass.

Transfer Belt, Fuser, Tray1 Roller, Tray2 Roller, MP Tray
Roller:
Displays the number of pages printed each item.

5. If you selected to print a supply information page, press OK to confirm.
6. Press Stop/Clear to return to ready mode.

Replacing the DADF rubber pad

You will need to replace the DADF (or ADF) rubber pad when there seems to be

a consistent problem with paper pickup or when its specified yield is reached.

ITEMS

YIELD (AVERAGE)

Fuser unit

Approx. 100,000 pages

DADF friction pad

Approx. 20,000 pages

DADF pick-up roller

Approx. 80,000 pages

Pick-up roller (Multi-purpose tray,
FCF

a

, Optional tray 2)

a. First cassette feeder (Tray1)

Approx. 70,000 pages

Friction pad (Multi-purpose tray,

FCF, Optional tray 2)

Approx. 70,000 pages
