2. Installing the Printer
1. Place the printer on a level surface.
CAUTION
The power switch must be Off while you connect any
cables to the printer.
2. If you are going to use the printer on-line, connect the
RS-232 (on-line) cable as shown.
3. If you are going to use the optional Monarch computer
keyboard, remove the keyboard from its separate shipping
carton. Then, remove the plastic cap from the end of the
keyboard cable and connect it to the keyboard connector
on the printer.
Power
Cord
Power
Switch
Keyboard
Connector RS-232
Cable
3
