9. Guide the ribbon down between the printhead and the
front of the printer and around the rollers as shown.
10. Place the take-up core (empty core) on the ribbon take-up
reel.
11. Gently slide the ribbon cores onto the reels while guiding
the ribbon around the printhead.
12. Press down firmly on the cores to ensure they are seated
on the ribbon reel bases.
Delivery
Core
Ribbon
Take-up
Reel
Printhead
Take-up
Core
5. Loading the Ribbon
21
