RAIDBank4 Owner’s Manual 29
Chapter 4. RAID Controls- Web Interface
Introduction
The RAIDBank4 controller firmware includes a complete HTML-based application that allows all
configuration and monitoring to be performed across any IP based network, and utilizes standard
web browsers for interfacing. This Chapter describes the menu and control structure for your
RAIDBank4 using the web interface. The RAIDBank4 configuration utility is firmware based and
its operation is independent of host computer type or operating system.
Preparation
To ensure proper communications between the RAIDBank4 and Web browser-based RAID
management, Please connect a standard, Cat5 Ethernet cable to the RJ45 network jack on
the back of your RAIDBank4 and atach to your existing network. In order to access the
web administration utility please note the IP address displayed on the LCD screen. Launch
your firmware-embedded TCP/IP & Web Browser-based RAID manager by entering http://
[IP Address] in your web browser. The RAIDBank4 controller default User Name is “admin”
and there is no password assigned from the factory. Please refer to section 6.2 for more
information regarding security.
Login Procedure
The controller will prompt for user ID and password when
initially logging in. The default user ID is “admin” and no
password (leave the password field blank). The RAIDBank4
ships without a password defined, but is user changeable to
protect the internal RAIDBank4 from unauthorized entry.)
Upon login, the unit will display the user interface and system
information as illustrated:
4-RAID Control-Web Interface
Note:
The Default User ID is
admin
There is no password by default;
leave the password blank when
logging in.
Note:
RAIDBank4’s web control
applet has been tested for use with
Microsoft Internet Explorer >6.x and
Netscape 4.7/Gecko based browsers
or newer, and Apple Safari. Other
browsers may be compatible, please
check
www.micronet.com/support for
the latest information.
