RAIDBank4 Owner’s Manual 27
6. Additional System Functions
The following system functions are located in the main menu and control miscellaneous
system functions.
6.1 Ethernet Configuration
The RAIDBank4’s Ethernet port is preconfigured for DHCP operation. This menu option
allows the user to reconfigure IP functionality for static IP address or custom MAC address.
6.1.1 DHCP (enabled by default)
DHCP (Dynamic Host Configuration Protocol) is a protocol that lets network administrators
manage centrally and automate the assignment of IP (Internet Protocol) configurations on a
computer network. Select this option if you wish to use the DHCP address services in your
network. Move the cursor bar to DHCP Function item, then press ENT to show the DHCP
setting. Select the “Disabled’ or ‘Enabled” option to enable or disable the DHCP function.
6.1.2 Manual (Static) IP Address
Select this option to manually configure the IP address of the controller. Make sure that the
assigned IP address is in the same range of your default router address and that it is unique
to your private network. To set a static IP address, move the cursor bar to the Main menu
Ethernet Configuration Function item and then press ENT. The Ethernet Configuration menu
appears on the screen. Move the cursor bar to Local IP Address item, then press ENT to show
the default address setting in the RAID controller. You can reassign the IP address of the
controller (use the UP/DOWN keys on the front panel for each digit.)
6.1.3 HTTP Port Number
The HTTP port number is the TCP Port used for the web
user interface. The default port is 80, and can be changed
per user specification. To access the web UI with a port
other then 80, point your browser to http://:
6.1.4 Telnet Port Number
The Default Telnet TCP port is 23, and can be changed per user specification.
6.1.5 SMTP Port Number
The Default Telnet TCP port is 25, and can be changed per user specification.
6.1.6 Ethernet Address
A MAC address stands for Media Access Control address and is your computer’s unique
hardware number. This option should not normally be modified.
6.2 View System Events
To view the RAIDBank4 events, select the “Show System Events” option and press ENT. The
system events logged will be displayed. System events are logged chronologically, and may
be scrolled through.
Note:
The RAIDBank4 cannot use
ports 7168-8191 for IP services.
3-RAID Control-LCD
