RAIDBank4 Owner’s Manual 28
6.3 Clear all Event Buffers
To clear all events in the system log, scroll to select the “Clear all Event Buffers” option and
press ENT. The confirmation message will be displayed and press the ENT to clear all event
buffers or ESC to abort the action.
6.4 Hardware Information
To view the RAIDBank4 controller’s hardware monitor information, Scroll to select the
“Hardware Information” option and press ENT. All hardware information will be displayed.
Scroll to browse all the hardware information. The Hardware Monitor Information provides the
temperature, fan speed (chassis fan) and voltage of the internal RAIDBank4. The temperature
items list the current states of the controller board and backplane.
The Platinum RAID has an audiovisual alert system to inform the user of environmental
failure. The warning messages will indicate through the LCD, LED and alarm buzzer. The
following is a table of monitoring threshhold values:
Monitored Item Warning Condition
Controller Board Temperature > 60° Celsius
Controller Fan Speed < 1900 RPM
Power Supply +12V < 10.5V or > 13.5V
Power Supply +5V < 4.7V or > 5.3V
Power Supply +3.3V < 3.0V or > 3.6V
CPU Core Voltage +1.2V < 1.08V or > 1.32V
6.5 System Information
Choose this option to display Main processor, CPU Instruction cache/ and data cache size,
firmware version, serial number, controller model name, and the cache memory size. To check
the system information, press ENT to enter the main menu. Scroll to select the Show System
Information option, and then press ENT. All major controller system information will be
displayed. Scroll to browse all the system information.
3-RAID Control-LCD
