25
At a glance
Instrument cluster
Item Page
1 L Left turn signal indi-
cator lamp
2 v ABS/ ESP warning
lamp
357
3 Speedometer
4 Multifunction display
145
5 l Distance warning
lamp
Vehicles without Distronic*:
Warning lamp without func-
tion. It illuminates with the
ignition on. It should go out
when the engine is running.
361
6 K Right turn signal indi-
cator lamp
7 Coolant temperature indi-
cator with:
• Coolant temperature
warning lamp
361
Item Page
8 Tachometer with:
1 Supplemental Re-
straint System
indicator lamp
364
- Antilock Brake Sys-
tem (ABS) indicator
lamp
356
< Seat belt telltale 362
B Low beam headlamp
indicator lamp
50
A High beam headlamp
indicator lamp
137
9 Main odometer with:
ț Selector lever position 46
ț Program mode 179
a Clock with: 159
; Brake warning lamp,
USA only
358
3 Brake warning lamp,
Canada only
358
Item Page
? Engine malfunction
indicator lamp, USA
only
359
± Engine malfunction
indicator lamp, Cana-
da only
359
H Tire inflation pres-
sure warning lamp*
363
q Preglow indicator
lamp, Diesel engine
only
47
b Fuel display with:
A Fuel reserve warning
lamp
362
c Reset button for:
ț Resetting trip odometer 143
ț Adjusting instrument
cluster illumination 142
ț Confirming new time set-
tings 159
