PREPARATION
FEATURES
PRECAUTIONS
CONNECTIONS
OTHERS
TROUBLE-
SHOOTING
Roller 3
Roller 2
Roller 1
Print paper
Front
Roller
Paper
Roller
Roller
Paper
Paper
INCORRECT
CORRECT
INCORRECT
3
3
3
3
3
Insert the print paper between roller 1 and 2.
4
4
4
4
4
Insert the edge of the print paper to the roller 3.
·
Be sure to insert the paper straight.
5
5
5
5
5
Feed the print paper through the paper outlet with your hand.
1
6
6
6
6
6
Pull the print paper to eliminate slack.
7
7
7
7
7
Move the knob on the side of the printing unit to the direction as
indicated by the arrow.
NOTE
·
If too much paper is fed, ALARM lamp may light. In this case, press PAPER
FEED & CUT button.
