CP-31W
KEY FEATURES
■ High speed output –
16 seconds for S-size prints
■ Equipped with high-performance
DSP engine and 423 dpi
thermal head
■ Vivid, smear-free gradation
■ Large capacity 32MB memory
engineered to handle 8-frame
memory
■ Multi-print function for
application versatility
■ Low noise design
■ Easy-to-use, convenient front
access
■ Long lasting quality and
reliability
High Speed, Multi-Function
Printer With Exceptional Image
Quality And Reliability.
S P E C I F I C A T I O N S
Printing System Dye sublimation thermal transfer
Head Resolution 423 dpi
Print Resolution (Dots) 1600 x 1200 (S-size); 2100 x 1600 (L-size)
Gradation 256 gradation each for YMC; 16.7 million hue full color
Paper Size S-size 3.94 x 3.70" (100 x 94 mm); L-size 3.94 x 5.83" (100 x 148 mm)
Print Size S-size 3.78 x 2.83" (96 x 72 mm); L-size 3.78 x 5.00" (96 x 126 mm)
Paper Capacity 3P: S-size 80 sheets, L-size 50 sheets; 4P: S-size 60 sheets, L-size 40 sheets
Print Speed 3P: S-size approx. 16 sec., L-size approx. 25 sec.;
4P: S-size approx. 20 sec.; L-size approx. 31 sec.
Interface S video, composite video
Memory Capacity 8-frame memory
Control Terminal RS-232C (D-Sub 25 pin) rear mounted remote port (Mini DIN 8 pin, stereo mini-jack)
Dimensions (W x H x D) 8.35 x 4.92 x 16.73" (212 x 125 x 425 mm)
Weight 16.7 lbs. (7.6 kg) main unit only
Power Supply 120V AC 50/60 Hz; 220-240V AC 50/60 Hz
Power Consumption 120V AC 50/60 Hz: 1.7A (printing), 0.3A (standby)
220-240V AC 50/60 Hz: 1.0A (printing), 0.3A (standby)
Regulatory Approvals EN60950-1, EN60601-1, EN60601-1-2,TUV-GS, TUV-GM,UL60950-1, UL6060-1
CSA C22.2 No. 60950-1, No. 60601.1
Accessories AC power cord, paper cassette, instruction manual
NOTES: Print speed and power consumption are valued for “standard” printing mode.
The printer is not a medical device, thus, any printed images are for reference only and it should not be used for diagnosis
unless such application has been designed under approval as diagnostic imaging equipment.
O P T I O N S (Paper/Ink Ribbon Sets and Footswitch)
CK30S S-size printing paper and ribbon cartridge, 80 sheets x 3 packs
CK30L L-size printing paper and ribbon cartridge, 50 sheets x 4 packs
CK30S4P S-size overcoat printing paper and ribbon cartridge, 60 sheets x 3 packs
CK30L4P L-size overcoat printing paper and ribbon cartridge, 40 sheets x 4 packs
R800F Footswitch
ANALOG COLOR PRINTER
