22
Specifications
Specifications
Power Output
200 watts is the minimum sine wave continuous average
power output per channel, both channels operating
Output Load Impedance
2, 4 or 8 ohms
Rated Power Band
20Hz to 20,000Hz
Total Harmonic Distortion
0.005% maximum with both channels operating from 250
milliwatts to rated power, 20Hz to 20,000Hz
Dynamic Headroom
2.0dB
Frequency Response
+0, -0.5dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
Preamplifier Output 1 and 2 (for rated input)
1.4V unbalanced (8V Maximun)
Sensitivity (for rated output)
High Level, 250mV unbalanced, 500mV balanced
Phono, 2.5 mV
Power Amp In, 1.4V
Signal To Noise Ratio (A-Weighted)
High Level, 92dB below rated output
Phono, 84dB below 5mV input
Power Amplifier, 115 below rated output
Intermodulation Distortion
0.005% maximum, if the instantaneous peak power is 400
watts or less per channel with both channels operating for
any combination of frequencies from 20Hz to 20,000Hz
Wide Band Damping Factor
Greater than 40
Input Impedance
High Level, 20K ohms
Phono, 47K ohms; 65pF
Power Amp In, 10K ohms
Maximum Input Signal
High Level, 8V unbalanced, 16V balanced
Phono, 80mV
Power Amplifier In, 16V
Preamplifier Output Impedance
220 ohms
Power Guard
Less than 2% THD with up to 16dB overdrive at 1,000Hz
Voltage Gain
High Level to Rec Output: 0dB
High Level to Output 1 and 2: 15dB
Phono to Rec Output: 40dB
Phono to Output 1 and 2: 55dB
Power Amplifier: 29dB
Tone Controls
Bass Control ±12dB (1dB steps) @ 30Hz
Treble Control ±12dB (1dB steps) @ 10,000Hz
Power Requirements
100 Volts, 50/60Hz at 5.2 amps
110 Volts, 50/60Hz at 4.8 amps
120 Volts, 50/60Hz at 4.4 amps
220 Volts, 50/60Hz at 2.45 amps
230 Volts, 50/60Hz at 2.35 amps
240 Volts, 50/60Hz at 2.25 amps
Standby: Less than 1 watt
Note: Refer to the rear panel of the MA6600 for the correct
voltage.
Overall Dimensions
Width is 17-1/2 inches (44.45cm)
Height is 9-7/16 inches (23.97cm) including feet
Depth is 22 inches (55.88cm) including the Front Panel,
Knobs and Cables
Weight
75 pounds (34.1 kg) net, 93 pounds (42.3 kg) in shipping
carton
Shipping Carton Dimensions
Width is 29-1/2 inches (74.93cm)
Depth is 29 inches (73.66cm)
Height is 17 inches (43.18cm)
