1 2 3 4 56
12 11 10 9 8 7
1. VOLUME Down/Navigation Left Button - Press
to lower the volume or navigate left in the setting
menu.
2. MENU/ENTER Button - Press to access the on-
screen menu or press to enter the setting.
3. VOLUME UP/Navigation Right Button - Press to
raise the volume or navigate right in the setting
menu.
4. POWER Button - Press to turn the TV on; the
POWER indicator will light green. Press again to
turn the TV off; the POWER indicator will light red.
5. CHANNEL/NAVIGATION Down Button - Press
to select a lower-numbered channel or navigate
down in the setting menu.
6. CHANNEL/NAVIGATION Up Button - Press to
select a higher-numbered channel or navigate up
in the setting menu.
7. Left Speaker
8. Screen
9. Base Stand
10. REMOTE SENSOR
11. POWER Indicator–Lights green when the unit is
on, and lights red when the unit is off.
12. Right Speaker
5
LOCATION OF CONTROLS
POWER SOURCE
FRONT
To operate the unit using AC power, connect the AC adapter (included) to the DC 12V
IN jack (z) on the rear of the unit. Connect the AC cord to the adapter and
connect the other end to a wall outlet having 120V AC, 60Hz only.
NOTE: When you turn on the unit, the AC adapter will become warm or hot. This is
normal and it is suggested to put the AC adapter in a cool place.
3-pronged
Receptacle
Receptacle
Box Cover
3-pronged
plug
When using a 3-pronged plug
