Grandstream Networks, Inc. GXW-400x User Manual Page 32 of 39
Firmware 1.0.0.39 Last Updated: 5/2007
F IGURE 5: S CREEN - SHOT OF R EBOOTING P AGE
Grandstream Device Configuration
The device is rebooting now...
You may re-login by clicking on the link below in 30 seconds.
Click to re-login
All Rights Reserved Grandstream Networks, Inc. 2005
C ONFIGURATION THROUGH A C ENTRAL S ERVER
Grandstream GXW-400xs can be automatically configured from a central provisioning system.
When GXW-400x boot up, it will send TFTP or HTTP request to download configuration file,
“cfg000b82xxxxxx”, where “000b82xxxxxx” is the LAN side MAC address of the GXW-400x.
The configuration files can be downloaded via TFTP or HTTP from the central server. A service provider
or an enterprise with large deployment of GXW-400x can easily manage the configuration and service
provisioning of individual devices remotely from a central server.
Grandstream provides a licensed provisioning system called GAPS that can be used to support
automated configuration of GXW-400x. GAPS (Grandstream Automated Provisioning System) uses
enhanced (NAT friendly) TFTP or HTTP (thus no NAT issues) and other communication protocols to
communicate with each individual GXW-400x for firmware upgrade, remote reboot, etc.
Grandstream provide GAPS (Grandstream Automated Provisioning System) service to VoIP service
providers. It could be either simple redirection or with certain special provisioning settings. Initially upon
booting up, Grandstream devices by default point to Grandstream provisioning server GAPS, based on
the unique MAC address of each device, GAPS provision the devices with redirection settings so that
they will be redirected to customer’s TFTP or HTTP server for further provisioning. Grandstream also
provide GAPSLite software package which contains our NAT friendly TFTP server and a configuration
tool to facilitate the task of generating device configuration files.
The GAPSLite configuration tool is now free to end users. The tool and configuration template are
available for download from
http://www.grandstream.com/configurationtool.html
