Grandstream Networks, Inc. GXW-400x User Manual Page 23 of 39
Firmware 1.0.0.39 Last Updated: 5/2007
T ABLE 8: S TATUS P AGE D EFINITIONS
MAC Address The device ID in HEX format. This is needed for ISP troubleshooting. Note there
are separate MAC addresses for the WAN side and the LAN side.
WAN IP Address Shows WAN IP address of GXW–400x
Product Model Contains the product model info.
Software Version Program: This is the main software release. Boot and Loader are not changed
often.
System Up Time Shows system up time since the last reboot.
PPPoE Link Up Shows whether the PPPoE connection is running if connected to DSL modem.
NAT Shows type of NAT the GXW–400x is connected to via its WAN port. It is based
on STUN protocol.
Port Status Shows several information regarding the individual FXS ports.
Ex.
Port Hook Registration DND Forward Busy
Forward Delayed
Forward
FXS1 On
Hook Registered No 613
FXS2 Off
Hook Registered No 614
FXS3 On
Hook Not
Registered No
FXS4 On
Hook Registered Yes 615
** FXS port 4 user has set Do Not Disturb.
FXS port 1 user has set his calls to be forwarded unconditionally to ext 613
FXS port 2 user has set his calls to be forwarded to 614 when his phone is busy.
FXS port 3 user is not registered with his SIP Server.
A DVANCED U SER C ONFIGURATION
Log-in to the Advanced User Configuration Page the same way as for the basic configuration page. Log-
in using either of the following passwords: “admin” or “123”.
