Grandstream Networks, Inc. GXW-400x User Manual Page 29 of 39
Firmware 1.0.0.39 Last Updated: 5/2007
No Key Entry
Timeout Default is 4 seconds.
Early Dial Default is No. Use only if proxy supports 484 response. This parameter controls
whether the phone will send an early INVITE each time a key is pressed when a
user dials a number. If set to “Yes”, an INVITE is sent using the dial-number
collected thus far; Otherwise, no INVITE is sent until the “(Re-)Dial” button is
pressed or after about 5 seconds have elapsed if the user forgets to press the “Re-
Dial” button. The “Yes” option should be used ONLY if there is a SIP proxy
configured and the proxy server supports 484 Incomplete Address response.
Otherwise, the call will likely be rejected by the proxy (with a 404 Not Found error).
This feature is NOT designed to work with and should NOT be enabled for direct IP-
to-IP calling.
Dial Plan Prefix Sets the prefix added to each dialed number.
Use # as Dial
Key Allows users to configure the “#” key as the “Send” (or “Dial”) key. If set to “Yes”,
“#” will send the number. In this case, this key is essentially equivalent to the “Dial”
key. If set to “No”, this “#” key can be included as part of number.
Dial Plan Dial Plan Rules:-
1. Accept Digits: 1,2,3,4,5,6,7,8,9,0
2. Grammar: x - any digit from 0-9;
xx+ - at least 2 digit number;
^ - exclude;
[3-5] - any digit of 3, 4, or 5;
[147] - any digit 1, 4, or 7;
<2=011> - replace digit 2 with 011 when dialing
3. Example 1: {[369]11 | 1617xxxxxxx} - Allow 311, 611, 911, and
any 10 digit numbers of leading digits 1617
Example 2: {^1900x+ | <=1617>xxxxxxx} - Block any number of leading digits
1900 and
add prefix 1617 for any dialed 7 digit numbers
Example 3: {1xxx[2-9]xxxxxx | <2=011>x+} - Allow any length of number with
leading digit 2 and 10 digit-numbers of leading digit 1 and leading exchange number
between 2 and 9;
If leading digit is 2, replace leading digit 2 with 011 before dialing
4. Default: Outgoing - {x+}
Subscribe for
MWI Default is No. When set to “Yes” a SUBSCRIBE for Message Waiting Indication will
be sent periodically.
Send
Anonymous If this parameter is set to “Yes”, the “From” header along with Privacy and P_
Asserted_Identity headers in outgoing INVITE message will be set to anonymous,
blocking Caller ID.
Anonymous Call
Rejection Default is No. If set to Yes, incoming calls with anonymous Caller ID will be rejected
with 486 Busy message.
