Grandstream Networks, Inc.

GXW-400x User Manual

Page 13 of 39

Firmware 1.0.0.39

Last Updated: 5/2007

Five Success Tips when using the Voice Prompt

1. “*” shifts down to the next menu option

2. “#” returns to the main menu

3. “9” functions as the ENTER key in many cases to confirm an option

4. All entered digit sequences have known lengths - 2 digits for menu option and 12 digits for IP

address. For IP address, add 0 before the digits if the digits are less than 3 (i.e. - 192.168.0.26
should be key in like 192168000026. No decimal is needed).

5. Key entry can not be deleted but the phone may prompt error once it is detected

LACING A

HONE

ALL

Phone or Extension Numbers

1. Dial the number directly and wait for 4 seconds (Default “No Key Entry Timeout”); or

2. Dial the number directly and press # (Use # as dial key” must be configured in web configuration).

Examples:

1. Dial an extension directly on the same proxy, (e.g. 1008), and then press the # or wait for 4 seconds.

2. Dial an outside number (e.g. (626) 666-7890), first enter the prefix number (usually 1+ or international

code) followed by the phone number. Press # or wait for 4 seconds. Check with your VoIP service
provider for further details on prefix numbers.

IRECT

ALLS

Direct IP calling allows two parties, that is, a FXS Port with an analog phone and another VoIP Device, to
talk to each other in an ad hoc fashion without a SIP proxy.
Elements necessary to completing a Direct IP Call:

1. Both GXW400x and other VoIP Device, have public IP addresses, or

2. Both GXW400x and other VoIP Device are on the same LAN using private IP addresses, or

3. Both GXW400x and other VoIP Device can be connected through a router using public or private

IP addresses (with necessary port forwarding or DMZ).

GXW400x supports two ways to make Direct IP Calling:

Using IVR

1. Pick up the analog phone then access the voice menu prompt by dial “***”

2. Dial

“47” to access the direct IP call menu

3. Enter the IP address after the dial tone and voice prompt “Direct IP Calling”

Using Star Code

1. Pick up the analog phone then dial “*47”

2. Enter the target IP address.

Note: NO dial tone will be played between step 1 and 2.

Destination ports can be specified by using “*” (encoding for “:”) followed by the port number.

Examples:
