Grandstream Networks, Inc.
GXW-400x User Manual
Page 21 of 39
Firmware 1.0.0.39
Last Updated: 5/2007
E
ND
U
SER
C
ONFIGURATION
The GXW FXS Series uses an imbedded web-browser to simply the configuration process. There are six
(6) screenshots that the end user should become familiar with during the configuration process.
Download these pages now
http://www.grandstream.com/user_manuals/GUI/GUI_GXW400x.rar
and
review the term definitions found in Tables 7 – 11.
T
ABLE
7:
B
ASIC
S
ETTINGS
P
AGE
D
EFINITIONS
End User Password
Password to access the Web Configuration Menu. This field is case sensitive
with a maximum length of 25 characters.
Web Port
By default, HTTP uses port 80. This field is for customizable web port.
Telnet Server
Default is Yes.
IP Address
There are two modes to operate the GXW–400x :
DHCP mode: all the field values for the Static IP mode are not used (even
though they are still saved in the Flash memory.) The GXW–400x acquires its IP
address from the first DHCP server it discovers from the LAN it is connected.
Using the PPPoE feature: set the PPPoE account settings. The GXW–400x will
establish a PPPoE session if any of the PPPoE fields is set.
Static IP mode: configure the IP address, Subnet Mask, Default Router IP
address, DNS Server 1 (primary), DNS Server 2 (secondary) fields. These fields
are set to zero by default.
DHCP hostname
This option specifies the name of the client. This field is optional but may be
required by some Internet Service Providers. Default is blank.
DHCP domain
This option specifies the domain name that client should use when resolving
hostnames via the Domain Name System. Default is blank.
DHCP vendor class
ID
Used by clients and servers to exchange vendor-specific information. Default is
HT500.
PPPoE account ID
PPPoE username. Necessary if ISP requires you to use a PPPoE (Point to
Point Protocol over Ethernet) connection.
PPPoE password
PPPoE account password.
PPPoE Service
Name
This field is optional. If your ISP uses a service name for the PPPoE connection,
enter the service name here. Default is blank.
Time Zone
Controls how the date/time is displayed according to the specified time zone.
