Part identification chart – Gold's Gym XR66 GGSY69530 User Manual
Page 32
M10 x 48mm Bolt (23)
M10 x 45mm Bolt (78)
M10 x 53mm Carriage Bolt (83)
M10 x 25mm Button Screw (60)
M10 Nylon Locknut (75)
M8 Nylon Locknut (54)
M8 Washer (90)
M10 Small Washer (33)
M4 Washer (93)
M10 Large Washer (94)
M12 Locknut (95)
50mm Washer (59)
M4 x 25mm Self-tapping Screw (77)
M6 x 16mm Screw (79)
M6 x 20mm Screw (96)
M8 x 58mm Shoulder Bolt (89)
M12 Nut (95)
M10 Washer (74)
PART IDENTIFICATION CHART—
Model No. GGSY69530
R0903A
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
