t23036 37" Foot Shear
-25-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT23036001 TABLE 38 PN05M HEX NUT M16-1.5
2 PT23036002 CUTTER BAR 39 PW08M FLAT WASHER 16MM
3 PT23036003 HOLDDOWN 40 PSS10M SET SCREW M10-1.5 X 20
4 PT23036004 RIGHT SIDE PANEL 41 PT23036041 COMPRESSION SPRING
5 PT23036005 LEFT SIDE PANEL 41A PT23036041A SPRING CAP
6 PT23036006 FRONT EXTENSION ARM 42 PT23036042 SWIVEL TOP
7 PB24M HEX BOLT M12-1.75 x 45 43 PT23036043 SWIVEL BOTTOM
8 PT23036008 HOLDDOWN SPRING 44 PT23036044 SPRING STUD
9 PT23036009 HOLDDOWN SHAFT 45 PW08M FLAT WASHER 16MM
10 PN09M HEX NUT M12-1.75 46 PN13M HEX NUT M16-2
11 PT23036011 SPECIAL BOLT 47 PT23036047 SPRING MOUNTING BRACKET
12 PT23036012 SPECIAL WASHER 12MM 48 PSB64M CAP SCREW M10-1.5 X 25
13 PT23036013 FINGER GUARD 49 PW04M FLAT WASHER 10MM
14 PSB58M CAP SCREW M8-1.25 x 12 50 PT23036050 SPECIAL BOLT M12 X 70
15 PT23036015 LEFT TABLE SCALE 51 PT23036051 SPECIAL BOLT M12 X 50
16 PT23036016 RIGHT TABLE SCALE 53 PT23036053 FOOT PEDAL SHAFT
17 PB09M HEX BOLT M8-1.25 X 20 58 PT23036058 REAR EXTENSION ARM
18 PSS39M SET SCREW M10-1.5 X 50 59 PT23036059 REAR STOP
19 PSB47M CAP SCREW M10-1.5 X 40 60 PT23036060 REAR STOP BRACKET
21 PT23036021 SPECIAL BOLT M16-2 X 100 61 PT23036061 REAR STOP BLOCK
22 PW08M FLAT WASHER 16MM 62 PT23036062 ADJUSTER DIAL
23 PT23036023 SPECIAL NUT M16-2 63 PT23036063 ADJUSTER SHAFT
24 PT23036024 TOP BLADE 64 PN08M HEX NUT M10-1.25
25 PT23036025 BOTTOM BLADE 65 PT23036065 LOCK KNOB M8-1.25 X 25
26 PSB47M CAP SCREW M10-1.5 X 40 67 PT23036067 ADJUSTER BLOCK
27 PSB90M CAP SCREW M10-1.5 X 55 68 PT23036068 KNURLED SCREW M10-1.5 X 12
28 PW04M FLAT WASHER 10MM 70 PN02M HEX NUT M10-1.5
29 PW04M FLAT WASHER 10MM 71 PT23036071 FRONT STOP
31 PT23036031 GIB 72 PT23036072 T BOLT M10-1.5 X 45
32 PSB143M CAP SCREW M10-1.5 X 50 74 PWN04M WING NUT M10-1.5
33 PN02M HEX NUT M10-1.5 75 PT23036075 BEVEL GAUGE
34 PT23036034 STRAIGHTENER ROD 91 PT23036091 TOP SPRING CAP
35 PW08M FLAT WASHER 16MM 92 PT23036092 PEDAL FRAME
36 PN05M HEX NUT M16-1.5 93 PT23036093 BACK GAUGE ASSEMBLY
37 PT23036037 ADJ SCREW STRAIGHTENER ROD 94 PW06M FLAT WASHER 12MM
parts List
