1.0 SPECIFICATIONS
1.1 Technical Specifications
Performance
Data Rate: 10 Mbps or 100MB, per port
Aggregate Forwarding Rate: (all ports are wire speed)
2.38M frames/sec for 16 100Mbps ports (for Magnum 4K16)
2.68M frames/sec for 16 100Mbps ports & two fiber ports
(16RJ-45 +2 Fiber ports)
Aggregate Filtering Rate: (all ports are wire speed)
2.38M pps for all 16 ports
2.38M pps for all 18 ports (16 RJ-45 ports+ 2 Fiber ports)
Address Table Capacity: 4K node addresses, self-learning w/address aging
Packet buffer size : 512K dynamic
Latency: 5 µs + packet time (100 to 100Mbps)
15
µs + packet time (10 to 10 Mbps, and 10 to 100Mbps)
Network Standards
Ethernet V1.0/V2.0 IEEE 802.3: 10BASE-T,
IEEE 802.3u: 100BASE-TX, 100BASE-FX
Maximum 10 Mbps Ethernet Segment Lengths
Unshielded twisted pair, Cat 3 - 100 m (328 ft)
10BASE-FL multi-mode fiber optic - 2 km (6,562 ft)
10BASE-FL single-mode fiber optic - 10 km (32,810 ft)
Maximum Standard Fast Ethernet Segment Lengths:
10BASE-T (CAT 3, 4, 5 UTP) - 100 m (328 ft)
100BASE-TX (CAT 5 UTP) - 100 m (328 ft)
100BASE-FX, half-duplex, multi-mode - 412 m (1350 ft)
100BASE-FX, full-duplex, multi-mode - 2.0 km (6,562 ft)
100BASE-FX, half-duplex, single-mode - 412 m (1350 ft)
100BASE-FX, full-duplex, single-mode - 20.0 km (49,215 ft)
100BASE-FX, full-duplex, s.m(Long Reach)- 40.0 km (132,215 ft)
Connectors for copper wiring
Twisted Pair at 10/100Mb:RJ-45 shielded, female, front mounted
(for Magnum 4K-Series Fast Ethernet copper ports, use Cat 5 cable)
Fiber Multi-mode connector types:
Fiber Port, SC-type (snap-in): Fiber optic multi-mode, 100BASE-FX
Fiber Port, ST-type (twist-lock): Fiber optic multi-mode, 100BASE-FX
Fiber Port, MTRJ-type (plug-in): Fiber optic multi-mode, 100BASE-FX
Fiber Single-mode connector types:
Fiber Port, SC-type: Fiber optic single-mode, 100BASE-FX
Fiber Port, SC-type: Fiber optic "long-reach” single-mode, 100BASE-FX
