Magnum 4K16 Switches Installation and User Guide (12/05)
16
www GarrettCom com . .
3.2.2 Connecting Fiber Optic SC-type, "Snap-In"
The following procedure applies to installations using a FKM with SC-type
fiber connectors, i.e., using FKM-MSC, FKM-SSC single-mode, and FKM10-MSC.
When connecting fiber media to SC connectors, simply snap on the two square
male connectors into the SC female jacks of the FPM until it clicks and secures.
3.2.3 Connecting Single-Mode Fiber Optic
When using single-mode fiber cable, be sure to use single-mode fiber port
connectors. Single-mode fiber cable has a smaller diameter than multi-mode fiber cable
(9/125 microns for single-mode, 50/125 or 62.5/125 microns for multi-mode where xx/xx
are the diameters of the core and the core plus the cladding respectively). Single-mode
fiber allows full bandwidth at longer distances, and may be used to connect 100 Mb
nodes up to 10 Km 18Km with the FKM-SSC and 40 Km with the FKM-SSCL.
The same procedures as for multi-mode fiber applies to single-mode fiber
connectors. Follow the steps listed in Section 3.2.2 above.
3.2.4 Connecting MTRJ Fiber Optic “Snap-In”
The “MTRJ” is a multi-mode fiber connector considered as a “small form-
factor”, because of its small compact size. It looks almost like an RJ-45 port, but compact
in size and black color. The MTRJ’s small size and ease of connection make it a good
choice for 100Mbps fiber environment. FKM-MTRJ fiber may be used to connect 100
Mb nodes up to 2 Km at full duplex and 412m at half-duplex.
When connecting fiber media to MTRJ connectors, simply snap in the square
male connectors into the MTRJ female jacks of the FPM until it clicks and secures.
3.2.5 Connecting Twisted Pair (RJ-45,CAT3, CAT5, Unshielded or Shielded)
The RJ-45 ports of the Magnum 4K-Series can be connected to the following
two media types: 100BASE-TX and 10BASE-T. CAT 5 cables should be used when
making 100BASE-TX connections. When the ports are used as 10BASE-T ports, CAT 3
may be used. In either case, the maximum distance for unshielded twisted pair cabling is
100 meters (328 ft).
Media IEEE Standard Connector
Twisted Pair (CAT 3, 4, 5) 10BASE-T RJ-45
Twisted Pair (CAT 5) 100BASE-TX RJ-45
NOTE : It is recommended that high quality CAT. 5 cables (which work for both 10 Mb
and 100Mb) be used whenever possible in order to provide flexibility in a
mixed-speed network, since dual-speed ports are auto-sensing for either 10 and
100Mb/s.
The following procedure describes how to connect a 10BASE-T or 100BASE-
TX twisted pair segment to the RJ-45 port. The procedure is the same for both
unshielded and shielded twisted pair cables.
