Magnum 4K16 Switches Installation and User Guide

(12/05)

15

www GarrettCom com

.

.

3.2

Connecting Ethernet Media

The Magnum 4K16 Switches are specifically designed to support all

standard Ethernet media types within a single Switch unit. This is

accomplished by complementing standard RJ-45 copper parts with a family of

Fiber-port Modules (FKMs) which can be individually selected and configured

per-port. See Section 2.4 for a description of the FKMs.

The various media types supported along with the corresponding IEEE

802.3 and 802.3u standards and connector types are as follows:

IEEE Standard Media Type Max. Distance Port Module

Fiber:

100BASE-FX

m

m

1

Fiber

2.0km (6,562 ft)

FKM-MSC,

-MST

sgl.m

2

Fiber

20.0km (95K ft) FKM-SSC

sgl.m

2

Fiber

40.0km (12K ft) FKM-SSCL

small form factor

m

m

1

Fiber

2.0km (6,562 ft)

FKM-MTRJ,

Copper:

10BASE-T & 100BASE-TX twisted pair 100m (328 ft)

RJ45

1

mm = multi-mode

2

sgl.m = single-mode


3.2.1

Connecting Fiber Optic ST-type, “twist-lock”

The following procedure applies to installations using a FKM with ST-type fiber

connectors. This procedure applies to ports using a FKM-MST.

1.

Before connecting the fiber optic cable, remove the protective dust caps from the

tips of the connectors on the FKM. Save these dust caps for future use.

2.

Wipe clean the ends of the dual connectors with a soft cloth or lint-free lens tissue
dampened in alcohol. Make certain the connectors are clean before connecting.

Note:

One strand of the duplex fiber optic cable is coded using color

bands at regular intervals; you must use the color-coded strand on the
associated ports at each end of the fiber optic segment
.

3.

Connect the Transmit (TX) port (light colored post) on the Magnum FKM to the

Receive (RX) port of the remote device. Begin with the color-coded strand of

the cable for this first TX-to-RX connection.

4.

Connect the Receive (RX) port (dark colored post on the PM) to the Transmit
(TX) port of the remote device. Use the non-color coded fiber strand for this.

5.

The LINK LED on the front of the FKM will illuminate when a proper
connection has been established at both ends (and when power is ON in the unit).
If LINK is not lit after cable connection, the normal cause is improper cable
polarity. Swap the fiber cables at the FKM connector to remedy this situation.
