GarrettCom 4K16 User Manual
Page 4
Magnum 4K16 Switches Installation and User Guide
(12/05)
iii
www GarrettCom com
.
.
TABLE OF CONTENTS
Page
1.0 SPECIFICATIONS ............................................................................................ 1
1.1 Technical
Specifications .................................................................................. 1
1.2 Ordering
Information ....................................................................................... 3
2.0 INTRODUCTION .............................................................................................. 4
2.1
Inspecting the Package and Product................................................................. 4
2.2
Product Description - Magnum 4K16 Switches............................................... 5
2.2.1
Magnum 4K16F Switch chassis ............................................................. 5
2.2.2:
Magnum 4K16R “Reverse” model, front LEDs and connections in rear 6
2.2.3 Fiber-port module (FKM) options for 4K16’s and 4K16R’s, 100Mb fiber .. 7
2.2.4
4K16, 10/100 Dual-speed switched ports, RJ-45 (copper only).............. 8
2.2.5
Up-link Switch at port#1 for Cascading ................................................. 9
2.2.6 Frame
Buffering and Latency ................................................................. 9
2.3 Features
and Benefits ..................................................................................... 11
2.4 Applications ................................................................................................... 12
3.0
INSTALLATION ............................................................................................ 14
3.1 Locating
Magnum
4K16 Switches................................................................. 14
3.2 Connecting
Ethernet Media ........................................................................... 15
3.2.1
Connecting Fiber Optic ST-type, “twist-lock” ..................................... 15
3.2.2
Connecting Fiber Optic SC-type, "Snap-In" ......................................... 16
3.2.3 Connecting
Single-Mode Fiber Optic ................................................... 16
3.2.4 Connecting MTRJ Fiber Optic “Snap-In”................................................. 16
3.2.5
Connecting Twisted Pair (RJ-45,CAT3, CAT5, Unshielded) ............... 16
3.3 Rack-mounting................................................................................................. 17
4.0 OPERATION.................................................................................................... 18
4.1 Switching
Functionality ................................................................................. 18
4.2 Status LEDs ................................................................................................... 19
4.3
Up-link Switch, for RJ-45 Port#1 only .......................................................... 19
4.4
Auto-negotiation, for Fast Ethernet copper ports ........................................... 19
4.5 Auto-negotiation
full-duplex mode................................................................ 20
4.6 Flow-control,
IEEE 802.3x standard.............................................................. 21
4.7
Power Budget Calculations for 4K-Series FKM’s with Fiber Media............. 21
5.0
INTRODUCTION - MAGNUM 4K16 FIBER-PORT MODULES (FKM) 23
5.1 Product
Description ....................................................................................... 23
5.1.1
FKM-MST, 100Mbps multi-mode FX-ST-type, “twist-lock” connector23
5.1.2
FKM-MSC 100Mbps multi-mode FX-SC-type, “snap-in” connector. 23
5.1.3
FKM-SSC and –SSCL 100Mbps single-mode FX-SC-type, “snap-in” 23
5.1.4
FKM-MTRJ, 100Mb multi-mode FX, MTRJ small-form-factor ........ 24
5.1.5 FKM-Blank ........................................................................................... 24
6.0 TROUBLESHOOTING................................................................................... 25
6.1 Before
Calling
for Assistance ........................................................................ 25
6.2
When Calling for Assistance.......................................................................... 26
6.3
Return Material Authorization (RMA) ProcedureError! Bookmark not defined.
6.4
Shipping and Packaging Information............................................................. 27
APPENDIX A: WARRANTY INFORMATION ....................................................... 27
APPENDIX B : INTERNAL DC POWER SUPPLY OPTIONS............................... 28
APPENDIX C: INTERNAL DC DUAL-SOURCE POWER OPTION .................... 30
