GG0 Series Tip Selection Charts
For Models 239786 and 241469
GG0 and GG1 Series Spray Tips
Orifice Fan Width Flow Rate Part No. Orifice
Size Fan Width Flow Rate Part No.
0.065
(1.65) 8–8.5
(200–213) 4.53
(17.2) GG0465
( )
10–10.5
(250–263)
( )
GG0565
12–13
(300–325) GG0665
14–15
(350–375) GG0765
16–17
(400–425) GG0865
0.067
(1.70) 8–8.5
(200–213) 4.82
(18.2) GG0467
( )
10–10.5
(250–263)
( )
GG0567
12–13
(300–325) GG0667
14–15
(350–375) GG0767
16–17
(400–425) GG0867
28–29
(700–725) GG1467
0.069
(1.75) 8–8.5
(200–213) 5.11
(19.3) GG0469
( )
10–10.5
(250–263)
( )
GG0569
12–13
(300–325) GG0669
Orifice Fan Width Flow Rate Part No. Orifice
Size Fan Width Flow Rate Part No.
0.071
(1.80) 8–8.5
(200–213) 5.41
(20.5) GG0471
( )
10–10.5
(250–263)
( )
GG0571
12–13
(300–325) GG0671
16–17
(400–425) GG0871
28–29
(700–725) GG1471
0.073
(1.85) 8–8.5
(200–213) 5.72
(21.7) GG0473
( )
10–10.5
(250–263)
( )
GG0573
0.075
(1.90) 8–8.5
(200–213) 6.04
(22.9) GG0475
0.077
(1.95) 8–8.5
(200–213) 6.36
(24.1) GG0477
0.079
(2.00) 8–8.5
(200–213) 6.70
(25.4) GG0479
0.081
(2.06) 8–8.5
(200–213) 7.04
(26.7) GG0481
*Fluid output at 600 psi (4.1 MPa, 41 bar).
Fluid output (Q) at other pressures (P) can be calculated by this
formula: Q = (0.041) (QT) (
qP
).
Where QT = Fluid output (fl oz/min) from the above table for
the selected orifice size.
NOTE: Other tips are available on special work order. Allow 4
to 6 weeks for delivery.
