Zebra XiII Printer User’s Guide 59
Routine Care and Adjustment
Fuse Replacement
The Zebra XiII printer uses a metric-style fuse (5 X 20 mm IEC) rated at
F5A, 250V. The end caps of the fuse must bear the certification mark of a
known international safety organization (See Figure 20, “International
Safety Organizations,” on page 87). The printer comes with two approved
fuses: one in the circuit and one in the “spare fuse” holder.
1. Turn the printer power off and unplug the power cord from the back of
the printer. See Figure 12.
2. Using a small-blade screwdriver or similar tool, remove the Fuse Holder
from the printer.
3. Remove the faulty fuse and install a new fuse of the correct type. Refer
to Figure 13. The fuse that goes into the printer first is the one that is “in-
circuit”. If you use the spare fuse, be sure to order a replacement fuse
(fuses can be ordered from your Zebra distributor).
4. Snap the Fuse Holder back into position.
5. Reconnect the power cord.
If the new fuse fails right away, the printer has an internal component fail-
ure and must be repaired.
