18 Genie Z-34/22 & Genie Z-34/22N Part No. 43654
Operator's Manual Second Edition • Ninth Printing
Test the Lift/Drive Select Function
(CE models)
Machines with lift/drive select switch:
50 Move the lift/drive select switch to the lift
position.
51 Press down the foot switch.
52 Move the drive control handle off center.
Result: No drive functions should operate.
53 Activate each boom function toggle switch.
Result: All boom functions should operate.
54 Move the lift/drive select switch to the drive
position.
55 Press down the foot switch.
56 Activate each boom function toggle switch.
Result: No boom functions should operate.
57 Move the drive control handle off center.
Result: The drive functions should operate.
Machines without lift/drive select switch:
58 Press down the foot switch.
59 Move the drive control handle off center and
activate a boom function toggle switch.
Result: No boom functions should operate. The
machine will move in the direction indicated on
the control panel.
FUNCTION TESTS
Test Auxiliary Controls
60 Move the lift/drive select switch to the
appropriate position (if equipped).
61 Press down the foot switch.
62 Simultaneously hold the auxiliary power switch
on and activate each function control handle or
toggle switch.
Note: To conserve battery power, test each
function through a partial cycle.
Result: All boom, steer and drive functions
should operate.
