Identification – Grizzly G0517g User Manual
Page 7
Model G0517 Mill/Drill
-5-
A. ON/OFF Switch w/Safety Key
B. Belt Tension Handle
C. Belt Tension Locks
D. Headstock Clamp Handle
E. Head Elevation Crank (Z Axis, Major)
F. Column Lock
G. Longitudinal Handwheels (X Axis)
H. Splash Tray
I. Cross Feed Handwheel (Y Axis)
J. Cabinet Stand
K. Quill Lock
L. Quill
M. Arbor
N. Drill Chuck
O. Downfeed Handle (Z Axis, Minor)
P. Vise
Q. Milling Table
Identification
K
A
B
C
D
E
F
G
H
L
M
N
O
P
Q
J
I
