2

308237

WARNINGS

High Pressure Spray Can Cause Serious Injury. For Professional Use Only.

Observe All Warnings. Read and understand all instruction manuals before operating equipment.

FLUID INJECTION HAZARD

General Safety

This equipment generates very high fluid pressure. Spray from

the gun, leaks or ruptured components can inject fluid through

your skin and into your body, and cause extremely serious injury,

including the need for amputation. Also, fluid injected or

splashed into the eyes or on the skin can cause serious damage.
NEVER point the spray gun at any one or at any part of the body.

NEVER put your hand or fingers over the spray tip. NEVER try

to blow back" paint; this is not an air spray system.
ALWAYS have the tip guard in place on the spray gun when

spraying.
ALWAYS follow the PRESSURE RELIEF PROCEDURE, below,

before cleaning or removing the spray tip or servicing any sysĆ

tem equipment.
NEVER try to stop or deflect leaks with your hand or body.
Be sure equipment safety devices are operating properly before

each use.

Medical Alert--Airless Spray Wounds

If any fluid appears to penetrate your skin, get

EMERGENCY

MEDICAL CARE AT ONCE. DO NOT TREAT AS A SIMPLE

CUT

. Tell the doctor exactly what fluid was injected.

Note to Physician: Injection in the skin is a traumatic injury. It

is important to treat the injury surgically as soon as possible. Do

not delay treatment to research toxicity. Toxicity is a concern

with some exotic coatings injected directly into the blood stream.

Consultation with a plastic surgeon or reconstructive hand surĆ

geon may be advisable.

Spray Gun Safety Devices

This gun has several safety devices. Be sure all of them are operĆ

ating properly before each use. Do not remove or modify any

part of the gun; this can cause a malfunction and result in serious

injury.
Whenever you stop spraying, even for a moment, always set the

trigger safety latch in the engaged or safe" position, making the

gun inoperative. Failure to set the trigger safety latch can result

in accidental triggering of the gun. See Fig. 1.
ALWAYS have the tip guard in place on the spray gun while

spraying. The tip guard alerts you to the fluid injection hazard

and helps reduce, but does not prevent, the risk of accidentally

placing your fingers or any part of your body close to the spray

tip. See Fig. 2.
Always have the trigger guard in place on the gun when spraying

to reduce the risk of accidentally triggering the gun if it is

dropped or bumped. The fluid housing and heat shield act as a

trigger guard for this gun. See Fig. 2.

Spray Tip Safety

Use extreme caution when cleaning or changing spray tips. If the

spray tip clogs while spraying, engage the trigger safety latch

immediately. ALWAYS follow the PRESSURE RELIEF PROCEĆ

DURE, below, and then remove the spray tip to clean it.
NEVER wipe off build-up around the spray tip until the pressure

is fully relieved and the gun safety is engageed.

Pressure Relief Procedure

To reduce the risk of serious bodily injury, including fluid

injection, splashing fluid or solvent in the eyes or on the

skin, or injury from moving parts or electric shock, always

follow this procedure whenever you shut off the sprayer,

when checking or servicing any part of the spray system,

when installing, cleaning or changing spray tips, and

whenever you stop spraying.
. Engage the trigger safety latch.
. Shut off the power supply to the pump and close any

bleedĆtype master air valves.

. Disengage the trigger safety latch. Hold a metal part of

the gun firmly to the side of a grounded metal pail, and

trigger the gun to relieve pressure.

. Engage the trigger safety latch.
. Open the pressure drain valve (required in system),

having a container ready to catch the drainage. Leave

the valve open until you are ready to spray again.

If you suspect that the spray tip or hose is completely

clogged, or that pressure has not been fully relieved after

following the steps above, VERY SLOWLY loosen the tip

guard retaining nut or hose end coupling to relieve presĆ

sure gradually, then loosen completely. Now clear the tip

or hose.

MOVING PARTS HAZARD

Moving parts can pinch or amputate your fingers or other body

parts. KEEP CLEAR of moving parts when starting or operating

the sprayer. Follow the Pressure Relief Procedure, above, beĆ

fore checking or servicing any part of the sprayer, to prevent it

from starting accidentally.

RECOIL HAZARD

Due to the high pressure fluid emitted, a strong recoil action may

occur when you trigger this gun. If you are unprepared, your

hand could be forced back toward your body or you could lose

your balance and fall, resulting in serious injury

.
