Gateway TM 5150 - Manual (Page 9)

Chapter 1: Checking Out Your Notebook 7
B. PC Card slots Accepts two Type I or Type II PC Cards or
one Type III PC Card. Install Type III PC Card
in the bottom slot. Install one Zoomed Video
card in either slot.
C. PC Card eject
buttons
Push in to eject the PC Card. If the button is
in the stored position, fold it out and press to
eject the PC Card.
D. Kensington lock
slot
Attach Kensington lock into this slot.
E. Mic in Connect an external microphone to this port
to record audio. (1/8-inch/3.5 mm jack.)
F. Line in Connect an external audio input source
(computer, stereo, VCR, etc.) to this port to
record or play audio through the notebook
speakers (1/8-inch/3.5 mm jack.)
G. Line out Connect amplified speakers to this port to
play audio from the notebook (1/8-inch/3.5
mm jack.)
H. Speaker out/
Headphone jack
Connect external speakers or headphones to
this port. Supports small unamplified speak-
ers. (1/8-inch/3.5 mm jack.)
I. Volume wheel Adjust built-in speaker volume, external
speaker, and headphone volume. Other port
volume levels are controlled by multimedia
software.
Component Icon Description
