G0526 6" Jointer
J.
Hex Bolts
3
⁄
8
"-16 x
3
⁄
4
" ................................3
K.
Lock Washers
3
⁄
8
" ......................................3
Figure 5.
Jointer mounting hardware
bag contents.
Figure 7.
Large hardware bag contents.
Figure 8.
Handwheel bag contents.
Figure 6.
Pedestal switch hardware
bag contents.
L.
Hex Bolts
5
⁄
16
"-18 x 1" ................................4
M.
Flat Washers
5
⁄
16
" ......................................8
N.
Hex Nuts
5
⁄
16
"-18 ........................................4
O.
V-Belt Belt Guard ......................................1
P.
Hex Bolt
5
⁄
16
"-18 x 2
1
⁄
2
"................................1
Q.
Flat Washer
5
⁄
16
" ........................................1
R.
V-Belt A-54 ................................................1
S.
Fence Support Key W/Pin..........................1
T.
Tilt Lever W/Knob ......................................1
U.
Lock Handle
1
⁄
2
"-12 x 1
1
⁄
4
" ..........................1
V.
Flat Washer
1
⁄
2
" ..........................................1
W.
Special Nut
1
⁄
2
"-12 ......................................1
X.
3mm Allen Wrench ....................................1
Y.
8 X 10mm Wrench ....................................1
Z.
12 X 14mm Wrench ..................................1
AA.
Handwheels ..............................................2
BB.
Handwheel Handles..................................2
