To read more information about the RAID array, press to enter the Array Detail screen (Figure
8), which shows various information about the array, including the RAID mode, stripe block size, hard
drive model name, and hard drive capacity, etc.
Figure 8
Figure 7
After that, the Array List screen appears, displaying the RAID array that you have created (Figure 7).
To delete the array, press in the Array Detail screen. When the "Delete this array?" message
appears, press to confirm or to cancel. Press to return to the Array List screen.
To exit the NVIDIA RAID setup utility, press in the main menu or + in the Array List
screen.
Now, you can proceed to the installation of the SATA controller driver and operating system.
MediaShield Utility Nov 20 2006
- Array List -
[Ctrl-X] Exit [
    ] Select [B] Set Boot
[N] New Array [ENTER] Detail
Boot Status Vendor Array Model Name
No Healthy NVIDIA STRIPE 223.57G
Array 2: NVIDIA STRIPE 233.57G
- Array Detail -
RAID Mode: Striping
Striping Width : 2
Striping Block: 64K
Port Index Disk Model Capacity
1.0 0 ST3120026AS 111.79GB
1.1 1 ST3120026AS 111.79GB
[R] Rebuild [D] Delete [C] Clear Disk [ENTER] Return
