GA-M61PME-S2P Motherboard - 40 -
NV SATA RAID function
Enables or disables RAID for the integrated SATA 3Gb/s controller. Enabled allows you to
configure RAID for individual SATA channel. (Default: Disabled)
NV SATA 1 Primary RAID
Enables or disables RAID for the first channel of the integrated SATA 3Gb/s controller. This item is
configurable only if the NV SATA RAID function item is set to Enabled.
(Default: Enabled)
NV SATA 1 Secondary RAID
Enables or disables RAID for the second channel of the integrated SATA 3Gb/s controller. This item
is configurable only if the NV SATA RAID function item is set to Enabled.
Onboard Audio Function
Enables or disables the onboard audio function. (Default: Auto)
If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item
to Disabled.
On-Chip MAC Lan
Enables or disables the onboard LAN function. (Default: Auto)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item
to Disabled.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
Onboard Serial Port 1
Enables or disables the first serial port and specifies its base I/O address and corresponding
interrupt. Options are: Auto, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled.
Onboard Parallel Port
Enables or disables the onboard parallel port (LPT) and specifies its base I/O address and
corresponding interrupt. Options are: 378/IRQ7 (default), 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
Selects an operating mode for the onboard parallel (LPT) port. Options are: SPP (Standard Parallel
Port)(default), EPP (Enhanced Parallel Port), ECP (Extended Capabilities Port), ECP+EPP.
ECP Mode Use DMA
Selects DMA channel for the LPT port in ECP mode. This item is configurable only if Parallel Port
Mode is set to ECP or ECP+EPP mode. Options are: 3 (default), 1.
On-Chip USB
Configures the integrated USB controller.
V1.1+V2.0 Enables the integrated USB 1.1 and USB 2.0 controllers. (Default)
V1.1 Enables only the integrated USB 1.1 controller.
Disabled Disables the integrated USB 1.1 and USB 2.0 controllers.
Disabled will turn off all of the USB functionalities below.
