Page 92
B
Appendix
B-1
GFK-1084B
Communications Ports Characteristics
This appendix describes the Ethernet Interface serial ports and the AAUI port used to
connect to the network transceiver.
What this Appendix Contains
Information pertaining to the Serial Ports: Station Manager Port and Software Loader
Port
H Serial Port Pinouts
H Serial Cable Diagrams
Information pertaining to the Apple Attachment Unit Interface (AAUI) Port for Ethernet
communications
H AAUI Port Pinouts
H AAUI Cable Diagram
H Transceiver Unit Description
