GE 90-30 PLC User Manual

Page 70

3-37

GFK-1084B

Chapter 3 Programming Communications Requests

the COMMREQ function and then check for a non-zero value indicating that the
Ethernet Interface is responding to the COMMREQ. A good way to do this is to use
a MOVE WORD function block to zero the CRS word.

A status code of 1 in the low byte and 0 in the high byte indicates that the request
was successful. All other non-zero values indicate errors. Refer to the tables below
for a complete listing of major and minor error codes.

The following tables list the error codes that are reported in the COMMREQ Status word
after the execution of a COMMREQ function. These codes also may appear in Word 1 of
the Detailed Channel Status words.

Table 3-4. Major Error Codes

БББББ

Error Status

ББББББББББББББББББББ

Major Error Description

БББББ

Hexadecimal

ББББББББББББББББББББ

БББББ

01H

ББББББББББББББББББББ

Successful Completion. (This is the expected completion value in
the COMMREQ Status word.)

БББББ

02H

ББББББББББББББББББББ

Insufficient Privilege at server PLC. For a Series 90-70 server PLC, the
minor error code contains the privilege level required for the service
request.

БББББ

04H

ББББББББББББББББББББ

Protocol Sequence Error. The server CPU has received a message that is
out of order. Call GE Fanuc Automation for assistance.

БББББ

05H

ББББББББББББББББББББ

Service Request Error at server PLC. The minor error code contains the
specific error code. See table of Minor Error codes below.

БББББ

06H

ББББББББББББББББББББ

Illegal Mailbox Type at server PLC. Service request mailbox type is ei-
ther undefined or unexpected. Call GE Fanuc Automation for assistance.

БББББ

07H

ББББББББББББББББББББ

The server PLC CPUs Service Request Queue is full, usually due to
heavy CPU loading. The client should retry later. It is recommended
that the client wait a minimum of 10 milliseconds before sending anoth-
er service request.

БББББ

0bH

ББББББББББББББББББББ

Illegal Service Request. The requested service is either not defined or
not supported at the server PLC. (This value is returned in lieu of the
actual service request error (01h), to avoid confusion with the normal
successful COMMREQ completion.) Call GE Fanuc Automation for assis-
tance.

БББББ

11H

ББББББББББББББББББББ

SRTP Error Codes at server. An error was detected at the SRTP server.
See table of Minor Error codes below.

БББББ

82H

ББББББББББББББББББББ

Insufficient Privilege at client PLC. For Series 90-70 PLC, the minor er-
ror code contains the privilege level required for the service request.

БББББ

84H

ББББББББББББББББББББ

Protocol Sequence Error. The CPU has received a message that is out
of order. Call GE Fanuc Automation for assistance.

БББББ

85H

ББББББББББББББББББББ

Service Request Error at the client PLC. The minor error code contains
the specific error code. See table of Minor Error codes below.

БББББ

86H

ББББББББББББББББББББ

Illegal Mailbox Type. Service request mailbox type is either undefined
or unexpected. Call GE Fanuc Automation for assistance.

БББББ

87H

ББББББББББББББББББББ

The client PLC CPUs Service Request Queue is full. The client should
retry later. It is recommended that the client wait a minimum of 10 mil-
liseconds before sending another service request.

БББББ

8bH

ББББББББББББББББББББ

Illegal Service Request. The requested service is either not defined or
not supported. (This value is returned in lieu of the actual service re-
quest error (01h), to avoid confusion with the normal successful
COMMREQ completion.). Call GE Fanuc Automation for assistance.

БББББ

90H

ББББББББББББББББББББ

Client API error. See table of Minor Error codes below.
