Figure b-6. 10baset transceiver configuration – GE 90-30 PLC User Manual
Page 100
B
GFK-1084B
B-9
Appendix B Communications Ports Characteristics
TRANSCEIVER CABLE TO
ETHERNET INTERFACE
a45490
10 BASE T
CABLE
RJ-45
CONNECTOR
Figure B-6. 10BaseT Transceiver Configuration
PWR
SQE
XMT
RCV
CP
SQE
must be
ON.
NOTE
a45489C
TRANSCEIVER CABLE TO
ETHERNET INTERFACE
AAUI TO AUI
ADAPTER
15–PIN
MALE
CONNECTOR
10BASE5
COAXIAL
CABLE
TAP
AC POWER
ADAPTER
STANDARD
MAU
NOTE: THE AAUI TO AUI ADAPTER MAY BE CONNECTED TO THE STANDARD MAU
VIA A TRANSCEIVER CABLE (UP TO 50 METERS)
Figure B-7. AAUI to AUI Adapter. Can be used to connect to 10Base5 (shown above) or
10BaseF
