Replacing the system board
www.gateway.com
Screws removed during this task:
4 black 2.5 × 4 mm
(diskette drive)
1 chrome 2 × 4 mm
(LCD cable) 4 chrome 2.5 × 6 mm
(hinges)
2 black 2.5 × 5 mm
(left hinge cover)
1 chrome 2.5 × 6 mm
(right hinge cover)
2 black 2.5 × 5 mm
(hard drive) 2 chrome 2.5 × 3 mm
(keyboard)
13 black 2.5 × 5 mm
(palm rest bottom)
3 black 2.5 × 5 mm
(palm rest back)
2 chrome 2.5 × 6 mm
(palm rest top)
6 chrome 2 × 4 mm
(heat sink)
4 black 2.5 × 4 mm
1 chrome 2.5 × 6 mm
(fan)
6 chrome 5 × 9 mm
(rear I/O panel)
4 black 2.5 × 4 mm
(system board/
LED indicator panel shield)
