6 Genie Superlift Advantage Part No. 97550
Operator's Manual Third Edition • Third Printing
Legend
1 2 3 4
11
14 12
15
17
18
19
8
3 4
1 Winch
2 Cable
3 Mast
4 Carriage
5 Adjustable arm
6 Traveling wheels (optional)
7 Leg
8 Leg swivel caster
9 Straddle base
10 Arm lock knob
11 Leg retaining pin
12 Stabilizer (if equipped)
13 Hold-down bar (on opposite
side of machine)
5 6 5 7
9
10
8
14 Stabilizer brace
15 Standard base
16 Base swivel/lock caster with
brake
17 Load handling attachment
retaining pin
16
11 8 12 8 7 13 14
