WEATHER ICONS (aera 510 & 560)
From the ‘Home‘ Screen, touch the Weather Icon to access the second-level
Weather Icons.
Touch the following second-level Weather Icons to display the weather product on
the Weather Map:
NEXRAd Displays NEXRAD (NEXt-generation RADar).
Satellite Displays Satellite Mosaic cloud cover.
Echo Tops Displays Echo Tops.
Winds Displays Winds Aloft.
lightning Displays Lightning.
Storm Cells Displays Storm Cells.
mETAR
Displays METARs.
