Restoring interface defaults:
From the 'Home' Screen, touch Tools > Setup > Interface > menu >
Restore default.
S
erIAl
D
AtA
F
orMAtS
Garmin Data Transfer—the proprietary format used to exchange data with a PC or •
another Garmin aera.
NMEA Out—transmits NMEA position, velocity, and navigation data. •
Aviation In—the proprietary format used for connection to a Garmin panel- •
mounted GPS receiver. This eliminates the need to enter the destination on both
units.
Aviation In/NMEA & VHF Out—receives aviation data and transmits out both •
NMEA data, at 9600 baud, and VHF frequency tuning information to a Garmin
Nav/Comm radio.
TIS In—receives TIS data from a Garmin Mode S transponder or other compatible •
device.
TIS In/NMEA & VHF Out—receives TIS data and transmits out both NMEA data, at •
9600 baud, and VHF frequency tuning information to a Garmin Nav/Comm radio.
None—provides no interfacing capabilities. •
A
DvAnceD
nMeA o
utput
S
etup
If interfacing the aera with another piece of equipment (such as an autopilot), the
unit needs to be set to output NMEA data. If the NMEA output mode is set to ‘Fast’,
the unit will output a minimum number of NMEA sentences at 1-second intervals. If
the NMEA output is set to ‘Normal’, the unit will output a greater number NMEA
sentences as 2-second intervals.
Setting NmEA output mode:
1) From the 'Home' Screen, touch Tools > Setup > Interface.
2) Touch Serial data Format. A vertical list is displayed.
3) Touch 'NmEA Out'.
4) Touch NmEA Output mode to toggle between 'Normal' or 'Fast'.
