14 Gateway ALR 9000 User’s Guide
• Power Supply LED, when lit, indicates that the power supply is
active.
• On/Off Switch turns the power supply on or off.
• Pull-Out Handle allows ease of installation or replacement of the
power supply.
AC-In Power Connector A
This socket conveys power to power supplies 1 and 2. Connect the system
power cable to this socket and to an AC outlet.
AC-In Power Connector B
This socket conveys power to power supplies 3 and 4. Connect the system
power cable to this socket and an AC outlet.
