10 Gateway ALR 9000 User’s Guide
Bezel Doors
The top bezel door offers access to the Power, Reset, and Keyboard Inhibit
switches, as well as the 3.5-inch and the upper 5.25-inch drives. The lower
bezel door offers access to the lower 5.25-inch drives.
Storage Bays
The system is equipped with fourteen storage bays which can support up to
78-GB of fixed media storage.
• three 3.5-inch bays: one with factory-installed 1.44-MB 3.5-inch
floppy diskette drive, one external front-accessible bay, and one
internal-accessible bay
• five 5.25-inch bays (one with factory-installed SCSI CD-ROM
Drive): all front-accessible and can support any 5.25-inch device or
3.5-inch device with a special mounting bracket
• six 3.5-inch Quick Hot Swap bays housed in a RAIDCage
(RAIDCage 6D) which also supports 1-inch and 1.6-inch devices
Keyboard Inhibit Switch
The keyboard inhibit switch can be locked to prevent unauthorized access
to the system. When locked, the keyboard will not function.
Power On/Off Switch
The power switch is a rocker assembly. Rock the switch up ( I ) to power the
system ON, rock the switch down ( 0 ) to power the system OFF.
LED Indicators
The front panel includes three LED indicators that signal a specific
message when illuminated:
LED Meaning (when illuminated)
Power Power is ON.
Hard Disk Activity Hard disk is in use.
Reserved (for future use)
