EasyCoder PC4 User’s Guide
47
Appendix B — Media Specifications
Tags and Strip with Slots
← a → Tag or strip width:
Maximum:
116.0 mm
(4.57 inches)
Minimum:
25.0 mm
(1.00 inches)
← b → Tag length:
Minimum:
6.35 mm
(0.25 inches)
← c → Detection slot width:
Minimum:
14 mm
(0.55 inches)
← d → Detection slot height:
Maximum:
10 mm
(0.39 inches)
Minimum:
1 mm
(0.08 inches)
The label gap sensor is offset 4.5 mm (0.177 inches) to the right of the center of the
media path.
a
c
TICKETS,TAGS, &
CONTINUOUS STRIP
d
b
