Identification – Grizzly G0561 User Manual
Page 5
g0561 7" x 12" Metal-Cutting Bandsaw
-3-
Identification
A. Blade tension handle
B. Blade guide Adjustment Knob
C. Coolant Control valve
D. Motor on/oFF switch
E. 1 hp Motor
f. Feed on/oFF valve lever
figure 1. Main view of machine features.
A
B
e
C
G. pump on/oFF switch
h. Automatic shut-off tab
I. vise handwheel
J. Blade guides
K. Blade tracking Controls
L. Feed rate Control Knob
g
i
F
J
h
K
d
l
