g0561 7" x 12" Metal-Cutting Bandsaw
-37-
it is always a good idea during the life of your saw
to check and adjust this setting. this adjustment
will improve your cutting results and extend the
life of your blade.
To square the blade to the bed of the table:
1. unplug the BAndsAW!
2. lower the head of the bandsaw all the way
until it contacts the horizontal stop.
3. place a square on the table bed and against
the edge of the blade ( figure 48), and check
different points along the length of the table
between the blade guides.
4. loosen the cap screw shown in figure 48,
and rotate the blade guide until the blade
is vertical to the bed, then tighten the cap
screw.
Note: Both blade guides can be adjusted to
achieve the results you want.
Squaring the Blade
figure 48. squaring the blade.
Cap screw
