Parts list – Grizzly G0561 User Manual
Page 46
-44-
g0561 7" x 12" Metal-Cutting Bandsaw
parts List
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
1
P0561001
BASE
65
P0561065
FILTER
2
P0561002
ACME SCREW 22 x 5 x 480
66
P0561066
SWITCH CUT OFF TIP
3
PW01
FLAT WASHER 1/2
67
PB24
HEX BOLT 3/8-16 X 1-1/4
4
PK20M
KEY 5 X 5 X 15
68
PW07
FLAT WASHER 5/16
5
P0561005
WHEEL
69
PN02
HEX NUT 5/16-18
5-1
P0561005-1
HANDLE
70
P0561070
SWITCH COVER
7
P0561007
FIXED BOLT 3/8 - 16
71
P0561071
TOGGLE SWITCH COVER
8
PW02
FLAT WASHER 3/8
72
PB03
HEX BOLT 5/16-18 X 1
9
P0561009
VISE JAW BRACKET (FRONT)
75
PS06
PHLP HD SCR 10-24 X 3/8
10
PRP77M
ROLL PIN 5 X 34
77
P0561077
STAND COMPLETE ASSEMBLY
11
P0561011
BRACKET
78
P0561078
HOSE 5/8 X 200MM
12
P0561012
ACME NUT ASSY 22 x 5
82
P0561082
COOLANT TANK
17
PB16
HEX BOLT 3/8-16 X 1-1/2
84
P0561084
PUMP (PLASTIC) V1.09.04
18
PN06
HEX NUT 1/2-12
85
PS12
PHLP HD SCR 1/4-20 X 5/8
19
PW01
FLAT WASHER 1/2
86
PW06
FLAT WASHER 1/4
20
P0561020
CARRIAGE BOLT 1/2-12 x 2
88
P0561088
COUPLER 3/8 PT X 5/16
21
PB42
HEX BOLT 1/2-12 X 2
89
P0561089
HOSE CLIP 5/8
22
P0561022
VISE JAW BRACKET (REAR)
90
P0561090
HOSE OD12 X ID8 X 2000
23
P0561023
BUSHING
91
P0561091
FITTING
24
P0561024
SUPPORT ROD
94
P0561094
WHEEL ROD
25
PB07
HEX BOLT 5/16-18 X 3/4
95
P0561095
WHEEL
26
P0561026
PIVOT BRACKET
96
P0561096
COTTER PIN 3 X 25
27
P0561027
WASHER 75 x 25.4
97
P0561097
CYLINDER COMPLETE SET RF-712N
28
PB16
HEX BOLT 3/8-16 X 1-1/2
99
PW07
FLAT WASHER 5/16
29
P0561029
SUPPORT PLATE
100
PB03
HEX BOLT 5/16-18 X 1
30
P0561030
FIXED PLATE
101
P0561101
CAP SCREW 3/8-16 X 2-1/2
31
P0561031
SPRING 32 x 282
102
PW02
FLAT WASHER 3/8
32
P0561032
SPRING ADJUSTING ROD
115
PS05M
PHLP HD SCR M5-.8 X 8
33
P0561033
SPRING HANDLE BRACKET
135
PW07
FLAT WASHER 5/16
34
PB07
HEX BOLT 5/16-18 X 3/4
136
PB07
HEX BOLT 5/16-18 X 3/4
35
PW07
FLAT WASHER 5/16
201
P0561201
GEAR BOX ASSEMBLY
36
PN08
HEX NUT 3/8-16
201-1
P0561201-1
GEAR BOX
37
PW02
FLAT WASHER 3/8
201-2
P0561201-2
TRANSMISSION WHEEL SHAFT
38
P0561038
THUMB SCREW 5/16-18
201-3
P0561201-3
BUSHING
39
PB07
HEX BOLT 5/16-18 X 3/4
201-4
P0561201-4
BUSHING
40
P0561040
WORK STOP ROD
201-5
P6205
BALL BEARING 6205ZZ
41
P0561041
WORK STOP
201-6
P0561201-6
WORM GEAR KEY
42
PB02
HEX BOLT 1/4-20 x 5/8
201-7
PR11M
EXT RETAINING RING 25MM
43
PN02
HEX NUT 5/16-18
201-8
P0561201-8
GEAR BOX GASKET
45
P0561045
SUPPORT PLATE
201-9
P0561201-9
GEAR BOX COVER
46
PB25
HEX BOLT 3/8-16 X 1-3/4
201-10 PS04
PHLP HD SCR 1/4-20 X 1/2
47
PN08
HEX NUT 3/8-16
201-11 P0561201-11 VENT PLUG
48
PB07
HEX BOLT 5/16-18 X 3/4
201-12 P0561201-12 BEARING COVER
49
PW07
FLAT WASHER 5/16
201-13 PS06
PHLP HD SCR 10-24 X 3/8
50
PB25
HEX BOLT 3/8-16 X 1-3/4
201-14 P0561201-14 WORM GEAR
51
PN08
HEX NUT 3/8-16
202
P0561202
WORM GEAR SHAFT ASSEMBLY
52
PB07
HEX BOLT 5/16-18 X 3/4
202-1
P0561202-1
WORM SHAFT
53
PW13
FLAT WASHER 3/4
202-2
P0561202-2
BEARING BUSHING
55
P0561055
RUBBER PLATE
202-3
P6003
BALL BEARING 6003ZZ
57
P0561057
TOGGLE SWITCH ASSEMBLY
202-4
P0561202-4
INT RETAINING RING 17MM
59
PS06
PHLP HD SCR 10-24 X 3/8
