Inventory – Grizzly G0561 User Manual
Page 13
g0561 7" x 12" Metal-Cutting Bandsaw
-11-
figure 3. loose parts inventory.
B
A
C
Inventory
After all the parts have been removed from the
box, you should have the following items:
Box Contents (figure 3)
Qty
Metal-Cutting Bandsaw (not shown) ................. 1
A. Wheels ....................................................... 2
B. Axle ............................................................ 1
C. leveling Feet with hex nuts ....................... 2
D. Chip screen ................................................ 1
E. Work stop ................................................... 1
f. Work stop rods ......................................... 2
G. vertical Work table .................................... 1
h. table Bracket .............................................. 1
I. handle ........................................................ 1
J. pulley Cover ............................................... 1
K. Collar .......................................................... 1
hardware Bag
•
Flat Washers
3
⁄
8
" (leveling Feet) ................ 2
•
Cotter pins 3 x 30mm (Wheels) ................. 2
•
hex Bolts
5
⁄
16
"-18 x
11
⁄
2
" (handle) ............... 4
•
hex nuts
5
⁄
16
"-18 (handle) .......................... 4
•
Flat Washers
5
⁄
16
" (handle) ......................... 8
•
Wire nuts (for 220v Wiring) ........................ 2
•
Flat head screw
1
⁄
4
"-20 x
5
⁄
8
" (table) .......... 1
•
hex nut
1
⁄
4
" x 20 (table) ............................. 1
•
phillips head screws
1
⁄
4
"-20 x
5
⁄
8
"
(pulley Cover) ............................................. 2
•
Flat Washers
1
⁄
4
" (pulley Cover) ................. 4
•
Knob
1
⁄
4
"-20 x
5
⁄
8
" (pulley Cover) ................ 1
•
hex nuts
3
⁄
8
"-16 .......................................... 2
d
e
F
g
h
i
J
K
