FS-8700-127 Hanning & Kahl HCS-R Manual Page 8 of 17
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldServer.com
Tel: 408 262-2299 Fax: 408-262-2269 Toll_Free: 888-509-1970 email: [email protected]
5.3.2 Driver Specific Map Descriptor Parameters
Column Title Function Legal Values
Node_Name Name of Node to fetch data from
One of the Node Names
specified in Section 5.2.
HCSR_OnFrom
For Passive_Client Map Descriptor specify whether data
From Loop or On Loop or both should be stored.
On, From, OnFrom
HCSR_Loop
For Passive_Client Map Descriptor specify loop number for
which data should be stored.
1,2,3,4
Length*
Length of Map Descriptor
22 (min) for RDBC Map Descriptor:
24 if data_type is Dig_Input
21 for Passive_Client Map Descriptor.
It also depends upon HCSR_Data_Stages parameter
Refer to Appendix A.
22 or 24, 21
Data_Type* Specify how data will be stored. Refer to Appendix A.1
Ana_Input
Digi_Input
HCSR_Data_Stages*
Specify the number of stages to keep history of data
changes. 0 and 1 means no history
0,1,2,3
5.3.3 Timing Parameters
Column Title Function Legal Values
Scan_Interval Rate at which data is polled ≥0.001s
