6.3.3 Map Descriptor Example. - SMD_HCSR_01 Map Descriptor to Serve HCS-R clients.
// Server Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Length , Scada_Hold_Timeout
SMD_HCSR_01
, DA_HCSR
, 0
, Passive
, HCSR_01
, 22
, 5
The starting location
of data to serve within
the Data Array
The number of items within the Data
Array which will be used to prepare the
response to the HCS-R Client
Data Array name
defined in
Section 4
